SDR-480P-48
Output(s) 48.0V @ 10.00A
Power (with Airflow) 480 Watts
Power (convection) 0 Watts
Dimensions 5.06 x 4.93 x 3.35"
Operating Temperature -25 ~ +70°C
Safety Approvals
SDR-480P-48 Features:
* High efficiency 94% and low power dissipation
* 150% peak load capability
* Built-in active PFC function, PF>0.94
* Short circuit / Overload / Over voltage / Over temperature Protection
* Cooling by free air convection
* Built-in constant current limiting circuit
* Can be installed on DIN rail TS-35/7.5 or 15
* UL 508(industrial control equipment)approved
* EN61000-6-2(EN50082-2) industrial immunity level
* Built-in DC OK relay contact
* 100% full load burn-in test
Output(s) 48.0V @ 10.00A
Power (with Airflow) 480 Watts
Power (convection) 0 Watts
Dimensions 5.06 x 4.93 x 3.35"
Operating Temperature -25 ~ +70°C
Safety Approvals
SDR-480P-48 Features:
* High efficiency 94% and low power dissipation
* 150% peak load capability
* Built-in active PFC function, PF>0.94
* Short circuit / Overload / Over voltage / Over temperature Protection
* Cooling by free air convection
* Built-in constant current limiting circuit
* Can be installed on DIN rail TS-35/7.5 or 15
* UL 508(industrial control equipment)approved
* EN61000-6-2(EN50082-2) industrial immunity level
* Built-in DC OK relay contact
* 100% full load burn-in test
| Weight | 1.6000 |
|---|
