HT10X21-301 10.4" a-Si TFT-LCD Panel for HYUNDAI
| Data Sheet | HT10X21-301 10.4" a-Si TFT-LCD Panel for HYUNDAI |
| Panel Brand | HYUNDAI |
| Panel Model | HT10X21-301 |
| Panel Type | a-Si TFT-LCDPanel |
| Panel Size | 10.4" |
| Resolution | 1024(RGB)×768 (XGA) |
| Display Mode | FFS, Normally Black, Transmissive |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 170 cd/m2 (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
| Display Colors | 262K (6-bit) |
| Response Time | 40 (Typ.)(Tr+Td) (ms) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR?10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | CCFL |
| Signal Interface | LVDS (1 ch, 6-bit) |
| Input Voltage | 3.3V (Typ.) |
| Other Name | HTL0X2L-30L HT1OX21-3O1 |
