Sanyo 109S030 100V 0.12/0.1A 9/7W 2wires Cooling Fan
Data Sheet | Sanyo 109S030 100V 0.12/0.1A 9/7W 2wires Cooling |
Model | 109S030 |
Manufacturer | Sanyo Denki |
Description | FAN 80X25MM 100VAC |
Width | 25.00mm |
Voltage Range | - |
Voltage - Rated | 100VAC |
Termination | 2 Terminals |
Static Pressure | 0.114 in H2O (28.4 Pa) |
Size / Dimension | Square - 80mm L x 80mm H |
Series | San Ace 80 |
RPM | 2700 RPM |
Power (Watts) | 7.00W |
Operating Temperature | -22 ~ 140°F (-30 ~ 60°C) |
Noise | 30.0 dB(A) |
Material - Frame | Aluminum |
Material - Blade | Plastic |
Lifetime @ Temp. | 25000 Hrs @ 60°C |
Ingress Protection | - |
Features | - |
Fan Type | Tubeaxial |
Current Rating | 0.100A |
Bearing Type | Ball |
Approvals | CE, CSA, PSE, TUV, UL |
Air Flow | 22.3 CFM (0.624m³/min) |
Other Name | L09S030 1O9SO3O |
Product cannot use in warranty period because of product quality problems
Product is damaged in transit
Product is not delivered in time because of our reason
Buyers send an email to our customer service to describe the problem, and to provide evidence (clear photos, screenshots, or video)
We will check the problem in 1 working days. For eligible cases, we will provide a free replacement or full refund within 1-2 business days
If a return is required, the return shipping fee will be paid by us
Sanyo 109S030 100V 0.12/0.1A 9/7W 2wires Cooling Fan
Gross Weight | 0.4 |
---|
