Información de suministro
Este producto se pide al fabricante original y se suministra recién fabricado, con su embalaje original.
El plazo estimado habitual es de 20–40 semanas; algunos componentes con escasez de suministro pueden tardar más.
Los plazos dependen de la planificación de producción del fabricante y resultan difíciles de prever con precisión. Haremos un seguimiento continuo y todo lo posible para adelantar la entrega.
LTC3807EFE#TRPBF Analog Devices Switching Regulators & Controllers - 1 Reel (2500 pcs)
| Ficha técnica | LTC3807EFE#TRPBF Analog Devices Switching Regulators & Controllers - 1 Reel (2500 pcs) |
| Manufacturer | Analog Devices |
| Model | LTC3807EFE#TRPBF |
| Category | Switching Regulators & Controllers |
| Sales Unit | 1 Reel |
| Pack Qty (pcs) | 2500 |
| MOQ (pcs) | 2500 |
| Order Multiple (pcs) | 2500 |
| Device Package | 20-Lead TSSOP w/ EP |
| Packing Type | Reel |
| Operating temperature range | -40 to 125 °C |
| Package pin/lead count | 20 pins |
| Converter topology / function | Synchronous step-down controller with external N-channel MOSFET power stage External power components required |
| Operating input voltage range | 4 to 38 V Operating input range, not absolute maximum converter output and external components must meet the operating constraints |
| Regulated output voltage range | 0.8 to 24 V Externally programmed step-down output input headroom, duty-cycle and external-component limits |
| Regulated feedback voltage at 25°C | 0.792 to 0.808 V 0.8 V (Typ.) TA = 25°C VIN = 12 V VRUN = 5 V EXTVCC = 0 V ITH = 1.2 V feedback servo-loop test Full-temperature E-grade has wider 0.788 V to 0.812 V limits |
| Wide VIN Range | 4V to 38V (40V Abs Max) |
| Low Operating IQ | 50μA |
| Features | RSENSE or DCR Current Sensing Phase-Lockable Frequency (75kHz to 750kHz) Programmable Fixed Frequency (50kHz to 900kHz) Internal LDO Powers Gate Drive from VIN or EXTVCC No Current Foldback During Start-Up |
| Protection | Selectable Current Limit Output Overvoltage Protection |
| Very Low Dropout Operation | 99% Duty Cycle |
| Low Shutdown IQ | 14μA |
LTC3807EFE#TRPBF Analog Devices Switching Regulators & Controllers - 1 Reel (2500 pcs)
| Peso bruto | 1.643 |
|---|
