LTN140AT07-306 14.0" a-Si TFT-LCD,Panel for SAMSUNG
| Data Sheet | LTN140AT07-306 14.0" a-Si TFT-LCD,Panel for |
| 品牌 | 三星(SAMSUNG) |
| 型号 | LTN140AT07-306 |
| 类型 | a-Si TFT-LCD,Panel |
| 尺寸 | 14.0" |
| 分别率 | 1366(RGB)×768 (WXGA) |
| 显示模式 | TN, Normally White, Transmissive |
| 表面处理 | |
| 亮度 | 200 cd/m2 (Typ.) |
| 对比度 | 300 : 1 (Typ.) (Transmissive) |
| 显示颜色 | 262K (6-bit) |
| 响应时间 | 8 (Typ.)(Tr+Td) (ms) |
| 可视角度 | 45/45/15/35 (Typ.)(CR?10) (L/R/U/D) |
| 频率 | 60Hz |
| 光源类型 | WLED |
| 信号接口 | LVDS (1 ch, 6-bit) |
| 输入电压 | 3.3V (Typ.) |
| RoHS | RoHS Compliance |
| 应用 | Laptop |
| 别名 | LTNL40AT07-306 1TN140AT07-306 LTN14OATO7-3O6 |
In the following cases, we will make a free reissue or full refund
Product cannot use in warranty period because of product quality problems
Product is damaged in transit
Product is not delivered in time because of our reason
Process of free reissue or full refund
Buyers send an email to our customer service to describe the problem, and to provide evidence (clear photos, screenshots, or video)
We will check the problem in 1 working days. For eligible cases, we will provide a free replacement or full refund within 1-2 business days
If a return is required, the return shipping fee will be paid by us
LTN140AT07-306 14.0" a-Si TFT-LCD,Panel for SAMSUNG
| Gross Weight | 3 |
|---|
